KEY FEATURES
Large back-lit icon display
Heated display option available
Fully configurable via the fascia or PC using USB communication
Efficient power save mode
3 phase generator sensing
3 phase mains (utility) sensing (DSE6020 MKII only)
Generator/load power monitoring (kW, kV A, kV Ar, pf)
Generator overload protection (kW)
Generator/load current monitoring and protection
Breaker control via fascia buttons
Fuel and start outputs, configurable when using CAN
4 configurable DC outputs
4 configurable analogue/digital inputs
6 configurable digital inputs
Support for 0-10 V & 4-20 mA oil pressure sensors
Configurable staged loading outputs
CAN, MPU and alternator speed sensing in one variant
3 engine maintenance alarms
Engine speed protection
Engine hours counter
Engine pre-heat
Engine run-time scheduler
Engine idle control for starting & stopping
Fuel pump control
Real-time clock
Battery voltage monitoring
Start on low battery voltage
Configurable remote start input
1 alternative configuration
Comprehensive warning, electrical trip or shutdown protection upon a fault condition
LCD and LED alarm indication
Configurable event log (50)
