Hydraulic Flow Divider / Combiner, 50:50, 2.6-5.2 GPM, SAE 6 Ports

This 2-way hydraulic flow divider/combiner is made from zinc-plated steel and rated for 3,600 PSI. It divides flow at an approximately 50:50 ratio for systems supplied by one pump and operating two non-mechanically linked cylinders simultaneously. When flow direction is reversed, it combines the two circuits.

• Load holding: Matched internal diameters help provide load holding with minimal leakage.
• Synchronization: Cylinder stroke error tolerance of ±3% of maximum flow; synchronization differences are compensated at the end of the stroke.
• Connections: SAE 6 ports with Buna-N seals.
• Construction: Zinc-plated steel body, made in Europe to American standards.
• Operating temperature: -40°F to 140°F.

Same-day shipping: Orders placed by 3 PM ship the same day, excluding weekends and holidays.

Free ground shipping within the continental United States.

Made in Europe. 1-Year Warranty.

If you need help selecting the right hydraulic flow divider/combiner, call 973-344-5313.
