121130, JET 1/2SS-1C-30 1/2-Ton Electric Chain Hoist W/ 30′ LIFT 1PH
JET® SSC Series Electric Hoists combine safety and durability to operate in commercial and industrial applications. All models incorporate a slip clutch overload protection mechanism that prevents the hoist from lifting damaging loads above its rated capacity. They are available in single or three-phase configurations to suit your electrical needs. Single-phase models have a thermal overload protection design that keeps the hoist from overheating, while the three-phase models feature a reverse phase relay that protects the hoist from incorrect wiring. The industry-proven DC electro-magnetic brake increases safety by holding the load even when power is interrupted. The maintenance-free gear train incorporates a sealed oil bath, for reliability and durability. The JET® SSC Series Electric Hoist is available in 1/2-Ton to 5-Ton capacities with standard lifts of 10, 15, 20, 30, 40, 50, and 60 feet (custom lifts available).
Features:
- 24-volt push button controller with cable strain relief system for durability and reliability
- All steel construction
- NEMA 4X compliant push button control pendants
- Durable powder coat finish
- Grade 80 Load Chain- Grade 80 black oxide coated load chain for durability
- Limit Switches- Upper and lower limiting switches increase safety by preventing the load chain from over traveling
- Sealed Gear Train- Maintenance-free gear train incorporates a sealed oil bath that eliminates upkeep
- Thermal overload protection
Specifications:
- Stock Number: 121130
- Capacity (Lbs.): 1000
- Duty Cycle (%): 25
- Duty Cycle Rating: H3
- Lift (Ft.): 30
- Lifting Speed (FPM): 19
- Load Capacity (Tons): 1/2
- Max. Number of Starts (Per Hr.): 150
- Max. On-Time (Min. / Hr.): 15
- Motor (HP): 7/8 HP, 115 / 230V, 1 Ph
- Motor Phase: 1
- Overload Protection: Yes
- Prop 65: Cancer and Reproductive Harm
- Weight (Lbs.): 119
- Headroom (In.): 20-3/16
- Overall Width (In.): 10.24
- Motor Current (Amps): 8
