Details:
- Laser guide system indicates the cut line for reliable cuts every time
- Powerful 2.5 HP, 3,600 RPM Motor
- Quick connect Motor to pump plug for easy hook-up
- Sturdy built-in folding stand with 2 sets of wheels for convenient transport in opened or folded position
- Convenient reset button
- Move tile saw from one site to another with stand in opened or folded position
- Comes complete with 10″ diamond continuous rim blade, 45° and 90° rip guides, 45° bevel guide and blade wrench
Specifications:
- MODELKC-3310TS
- BLADE DIAMETER10″
- ARBOR DIAMETER5/8″
- CUTTING CAPACITY AT 45°18″
- CUTTING CAPACITY AT 90°24″
- DEPTH OF CUT CAPACITY3-3/4″
- SLIDING TABLE SIZE W/EXTENSIONS24-1/2″ x 18-1/2″
- MAX. PUMP FLOW16 L/min
- MOTOR15 Amp.
- NO LOAD SPEED4,500 RPM
- VOLTAGE120V, 1 phase, 60Hz
- ASSEMBLED DIMENSIONS (LXWXH) / WEIGHT58″ x 34″ x 47″ / 105 lbs
- PACKAGE DIMENSIONS (LXWXH) / WEIGHT42-3/4″ x 23-1/2″ x 21-1/4″ / 110 lbs
- UPC 7 72995 01692 1
