Simpson 2-1/16 x 9-1/2 Face-Mount Joist Hanger, Galvanized HU2.1/9 (MPN: HU2.1/9) is a heavy-duty, face-mount hanger engineered for structures requiring additional strength and enhanced safety factors. Built from 14-gauge steel with a G90 zinc galvanized coating, this hanger delivers reliable performance and corrosion resistance in demanding framing applications.
Key Features
- Heavy-duty face-mount design engineered for applications requiring increased strength and safety factors
- 14-gauge steel construction for superior load-bearing performance
- G90 zinc galvanized coating provides durable corrosion resistance
- Some models feature a skewable seat for flexible installation angles
- Seat can slope up to 45 degrees on select configurations, accommodating angled framing conditions
- Made in the United States
Specifications
- Model Number: HU2.1/9
- Gauge: 14
- W (in.): 2-1/8
- H (in.): 9-3/16
- B (in.): 2-1/2
- Coating/Material: Zinc Galvanized, G90
- Mount Type: Face-Mount
- Country of Origin: United States
Options
Contact us for Configurable Options and Special orders
Contact us
Frequently Asked Questions
- What type of mounting does the HU2.1/9 use?
- The HU2.1/9 uses a face-mount design, meaning it attaches directly to the face of the supporting header or beam, making it suitable for a wide range of structural framing installations.
- What gauge steel is used in the HU2.1/9?
- The HU2.1/9 is constructed from 14-gauge steel, providing the heavy-duty strength required for applications where additional load capacity and safety factors are critical.
- What corrosion protection does the HU2.1/9 have?
- The HU2.1/9 features a G90 zinc galvanized coating, which offers a high level of corrosion resistance suitable for use in a variety of construction environments.
- Can the HU2.1/9 accommodate angled or skewed installations?
- Some models in the HU series feature a skewable seat and a seat that slopes up to 45 degrees, allowing for greater flexibility when framing at non-standard angles. Contact us to discuss configurable options for your specific project needs.
Note: Product dimensions and/or fastener holes may differ from picture. Please see item description for specifications.
Download Specs Sheet: HU-HUC_Heavy-Duty_Face-Mount_Hangers.pdf
