TEMPO COMMUNICATIONS | PART PA1258
STRIPPER LCCST MINI-COAX
DESCRIPTION
- Self-regulating tension
- Adjust cutting depth on each blade for varying cable thicknesses with the included hex key
- Pre-set for common strip lengths
- Blades adjust for strip dimensions other than our standard pre-set units
SPECIFICATIONS
| Attribute name | Attribute Value |
|---|---|
| Application | For RG178, RG179, RG188, AT&T735(A), NT735, Belden 1855A, Belden 8218, RG180, RG187, RG188A, RG405 and more |
| Blade Type | Adjustable |
| Preset Strip Length | 0.344 IN Outer Jacket, 0.094 IN Inner Dielectric |
| Replacement Part | PA2263 Replacement Blade |
| Type | LC CST Mini |
| Item Status Date | 01012009 |
| Country of Origin | TW |
| UNSPSC | 43223312 |
| International Harmonize Code | 8205595510 |
| RoHS Indicator | U |
| MSDS Update Flag | N |
Common Questions About the Tempo PA1258 LC CST Mini-Coax Stripper
What is the Tempo PA1258 Mini-Coax Stripper used for?
The Tempo PA1258 LC CST Mini-Coax Stripper is designed for preparing a variety of miniature coaxial cables, including RG178, RG179, RG180, RG187, RG188, RG188A, RG405, Belden 1855A, Belden 8218, AT&T735(A), NT735, and more.
What are the preset strip lengths on the Tempo PA1258?
The PA1258 is preset for a 0.344-inch outer jacket strip length and a 0.094-inch inner dielectric strip length for fast, consistent cable preparation.
Can the cutting depth on the Tempo PA1258 be adjusted?
Yes. Each blade can be individually adjusted with the included hex key to accommodate different cable thicknesses and strip dimensions beyond the standard preset lengths.
At a Glance
• Professional LC CST stripper designed for miniature coaxial cables
• Compatible with RG178, RG179, RG180, RG187, RG188, RG405, and more
• Preset for 0.344-inch outer jacket and 0.094-inch inner dielectric strip lengths
• Adjustable blade depth accommodates varying cable thicknesses
• Self-regulating tension helps provide consistent cable preparation
• Uses the Tempo PA2263 replacement blade
